Diamana™ RB

LAUNCH MID+ SPIN MID FLEX PROFILE MED MED SOFT+
BUTT MID TIP

Diamana™ RB Overview

Diamana™ RB (Red Board) – the third profile in the most recent generation – is designed with all the traditional branding that made Diamana™ so beloved – including a return to the original 53/63/73/83 weight class designations – and all the engineering prowess and material innovation that made the brand dominant on tour.

Offering a slightly higher launch angle than BB, Diamana™ RB was engineered to promote ease of launch while also maintaining control down field. Diamana RB is a classic "Red Board” profile — not available since the 2nd Generation of Diamana — that features an active tip section while still retaining the same material technology package (see below) and low-torque control characteristics  as its lower 6th Generation launching counterparts.

Key Features Include:
- 80-ton DIALEAD Pitch Fiber in butt section to maximize stability and energy transfer
- High modulus 46-ton fiber in angle plies to lower torque without increasing weight
- Xlink Tech™ Resin System to increases the strength and durability of the shaft

Who should play it? Golfers looking to generate a little more speed through a shaft that has a little active tip section while also maintaining control down field.

Spin/Launch Chart

Fit Guide

DRIVER MPH/YDS <80/210 81-90/210-239 91-105/240-259 >106/260
Diamana™ RB 43 R2/R R/SR S/X
Diamana™ RB 53 R R/SR S/X X/TX
Diamana™ RB 63 R R/SR/S S/X X/TX
Diamana™ RB 73 S/X X/TX
Diamana™ RB 83 S/X TX
IMPORTANT: For reference only. Mitsubishi Golf recommends being fit by a professional fitter.

Diamana™ RB Specifications

Shaft Flex Length Weight/GMS Tip OD Tip Length Butt OD Torque Kick Point
Diamana™ RB 43 R2 46 44 0.335 3 0.596 5.1 MID
Diamana™ RB 43 R 46 45 0.335 3 0.598 5.1 MID
Diamana™ RB 43 SR 46 47 0.335 3 0.600 5.1 MID
Diamana™ RB 43 S 46 48 0.335 3 0.602 5.1 MID
Diamana™ RB 43 X 46 49 0.335 3 0.606 5.1 MID
Diamana™ RB 53 R 46 50 0.335 3 0.596 4.9 MID
Diamana™ RB 53 SR 46 52 0.335 3 0.596 4.9 MID
Diamana™ RB 53 S 46 54 0.335 3 0.598 4.9 MID
Diamana™ RB 53 X 46 55 0.335 3 0.600 4.9 MID
Diamana™ RB 53 TX 46 56 0.335 3 0.600 4.9 MID
Diamana™ RB 63 R 46 60 0.335 3 0.602 3.2 MID
Diamana™ RB 63 SR 46 61 0.335 3 0.602 3.2 MID
Diamana™ RB 63 S 46 61 0.335 3 0.602 3.2 MID
Diamana™ RB 63 X 46 62 0.335 3 0.602 3.2 MID
Diamana™ RB 63 TX 46 62 0.335 3 0.602 3.1 MID
Diamana™ RB 73 S 46 70 0.335 3 0.602 2.9 MID
Diamana™ RB 73 X 46 71 0.335 3 0.604 2.9 MID
Diamana™ RB 73 TX 46 72 0.335 3 0.604 2.9 MID
Diamana™ RB 83 S 46 80 0.335 3 0.604 2.8 MID
Diamana™ RB 83 X 46 81 0.335 3 0.604 2.8 MID
Diamana™ RB 83 TX 46 81 0.335 3 0.604 2.8 MID

Diamana™ RB Tip Trim Information

Driver 3 Wood 5 Wood 7 Wood 9 Wood
0" 0.5" 0.75" 1.0" 1.0"
